| Model | |
|---|---|
| Model | Binocular panoramic camera |
| Platform | |
| CPU | QCS605 |
| Operating system | PilotOS operating system based on Android 10 |
| Memory | |
| RAM | 6GB LPDDR4x |
| ROM | 64GB eMMC (Supports Micro SD expansion cards (UHS-1 speed 3)) |
| Connection | |
| WIFI | Supports 802.11b/g/n/ac 80MHz, 2.4G/5G dual-band. |
| Bluetooth | BT5.0 |
| Display screen | |
| Size | 3 - inch, 16:9 multi - touch, narrow bezel |
| Type | LCD display |
| Resolution | 854×480 |
| Surface | Anti - fingerprint, oleophobic coating (AF) |
| Brightness | Above 350 nits |
| Lens Module | |
| Sensor Model | IMX586 * 2, 1/2" Size, 48M, CMOS |
| Lens Type | Customized lens |
| Quantity | 2 fisheye lenses |
| Field of View | 200° DFOV |
| Photo mode | |
| Resolution | 5760×2880 |
| Photo Format | jpg/dng |
| Timer | 3s, 5s, 10s, 30s |
| Burst Mode | Interval shooting, Timed shooting |
| Manual Mode | EV: -2~+2ISO: 100-6400 |
| Recording mode | |
| Resolution | 8K, 7680×3840/10FPS/8bit; 5.7K, 5760×2880/30FPS/8bit |
| Encoding | H.264/H.265 optional |
| Bitrate | Max 120Mbps |
| White Balance | Auto/Manual; Daylight, Shade, Cloudy, Tungsten, Fluorescent |
| Video Mode | Slow motion, Time-lapse recording |
| EV | 2~+2 |
| ISO | 100~6400 |
| Video Format | MP4 |
| Battery | |
| Capacity | 1800mAh |
| Endurance | 5.7K recording for 70 minutes |
| Charging | Extreme conditions 0~100% in 75 minutes |
| Sensor | |
| Gyroscope | BMI270 |
Accelerometer | BMI270 |
Gravity Sensor | BMI270 |
| Indicator lights | |
| Indicator Light | 1 full-color LED (RGB) |
| Audio | |
| Speaker | 1 unit, single PA (Power Amplifier) |
Mic (Microphone) | 2-channel mic |
| Buttons | |
| Video Recording Key | Photo/Video/Stop recording/Long press to flip camera |
Power Key | Power on/Power off/Screen on/Screen off |
Custom Key | Quickly enter and switch user-defined shooting modes and parameters |
| Structure | |
| Dimensions | Main body: 132 * 52 * 23mm; Thickness at lens position: 35mm |
Body | Aluminum alloy + plastic cover, + plastic cover, raw material shell (no spray coating) |
| Weight | Main body: 205g |
| Language & Firmware | |
| Language | Chinese / English |
| Upgrade | OTA (Over-the-Air) |
| Environmental Parameters | |
| Operating Temperature | 0℃ ~ 40℃ |
Storage Temperature | -20℃ ~ 70℃ |
| Operating Humidity | 20% ~ 75% |
Storage Humidity | 20% ~ 90% |
